Envelope Encryption: MEK/DEK Pattern

Why Envelope Encryption?

Most applications encrypt data with a single key. If that key is compromised, everything is exposed.
TimOS needed something stronger – the ability to say with confidence: “We cannot read your data.”

Envelope encryption solves this with a two-tier key hierarchy:

┌─────────────────────────────────────────────────────────┐
│                    ENVELOPE ENCRYPTION                   │
├─────────────────────────────────────────────────────────┤
│                                                          │
│   MASTER ENCRYPTION KEY (MEK)                           │
│   ├── Stored in environment variable                    │
│   ├── Never stored in database                          │
│   └── Used to encrypt DEKs                              │
│                                                          │
│         ↓ encrypts                                       │
│                                                          │
│   DATA ENCRYPTION KEY (DEK) - One per user              │
│   ├── Generated on user signup                          │
│   ├── Stored encrypted in platform DB                   │
│   └── Used to encrypt user's actual data                │
│                                                          │
│         ↓ encrypts                                       │
│                                                          │
│   USER CONTENT - In vault database                      │
│   ├── Journal entries                                    │
│   ├── Pillar data                                        │
│   ├── Feels entries                                      │
│   └── Weekly recaps                                      │
│                                                          │
└─────────────────────────────────────────────────────────┘

The Implementation

Key Generation

When a user signs up, we generate a unique 256-bit DEK using cryptographically secure random bytes:

// api/src/services/encryption.ts
import crypto from 'crypto';

const ALGORITHM = 'aes-256-gcm';
const IV_LENGTH = 16;
const AUTH_TAG_LENGTH = 16;
const KEY_LENGTH = 32; // 256 bits

export function generateDEK(): string {
  return crypto.randomBytes(KEY_LENGTH).toString('hex');
}

export function encryptDEK(dek: string, mek: string): {
  encryptedKey: string;
  iv: string;
} {
  const iv = crypto.randomBytes(IV_LENGTH);
  const cipher = crypto.createCipheriv(
    ALGORITHM,
    Buffer.from(mek, 'hex'),
    iv
  );

  let encrypted = cipher.update(dek, 'utf8', 'hex');
  encrypted += cipher.final('hex');
  const authTag = cipher.getAuthTag();

  return {
    encryptedKey: encrypted + authTag.toString('hex'),
    iv: iv.toString('hex'),
  };
}

Encrypting User Content

Every piece of user content goes through the same encryption process. We use AES-256-GCM because it provides
both confidentiality and authenticity (the auth tag ensures the data hasn’t been tampered with):

export function encrypt(
  plaintext: string,
  dekHex: string
): { ciphertext: string; iv: string } {
  const iv = crypto.randomBytes(IV_LENGTH);
  const cipher = crypto.createCipheriv(
    ALGORITHM,
    Buffer.from(dekHex, 'hex'),
    iv
  );

  let encrypted = cipher.update(plaintext, 'utf8', 'hex');
  encrypted += cipher.final('hex');
  const authTag = cipher.getAuthTag();

  return {
    ciphertext: encrypted + authTag.toString('hex'),
    iv: iv.toString('hex'),
  };
}

export function decrypt(
  ciphertext: string,
  iv: string,
  dekHex: string
): string {
  const authTag = Buffer.from(
    ciphertext.slice(-AUTH_TAG_LENGTH * 2),
    'hex'
  );
  const encryptedData = ciphertext.slice(0, -AUTH_TAG_LENGTH * 2);

  const decipher = crypto.createDecipheriv(
    ALGORITHM,
    Buffer.from(dekHex, 'hex'),
    Buffer.from(iv, 'hex')
  );
  decipher.setAuthTag(authTag);

  let decrypted = decipher.update(encryptedData, 'hex', 'utf8');
  decrypted += decipher.final('utf8');
  return decrypted;
}

Database Schema

The dual-database architecture keeps encryption keys separate from encrypted content:

// Platform DB - stores encrypted DEKs
model UserDEK {
  id              String   @id @default(uuid())
  userId          String   @unique @map("user_id")
  encryptedKey    String   @map("encrypted_key")
  keyIv           String   @map("key_iv")
  keyVersion      Int      @default(1) @map("key_version")
  createdAt       DateTime @default(now())
  rotatedAt       DateTime?

  user User @relation(fields: [userId], references: [id])
  @@map("user_deks")
}

// Vault DB - stores encrypted content
model DailyEntry {
  id              String   @id @default(uuid())
  userId          String   @map("user_id")
  date            DateTime @db.Date

  // All content stored encrypted
  encryptedContent String  @db.LongText @map("encrypted_content")
  contentIv        String  @map("content_iv")

  createdAt       DateTime @default(now())
  updatedAt       DateTime @updatedAt

  @@unique([userId, date])
  @@map("daily_entries")
}

The Encryption Flow

Here’s what happens when a user saves a journal entry:

const userDek = await platformDb.userDEK.findUnique({
  where: { userId }
});

const dek = decryptDEK(
  userDek.encryptedKey,
  userDek.keyIv,
  process.env.MASTER_ENCRYPTION_KEY
);

const content = JSON.stringify({
  notes: "Today's reflection...",
  mood: "focused",
  energyLevel: 8
});

const { ciphertext, iv } = encrypt(content, dek);

await vaultDb.dailyEntry.create({
  data: {
    userId,
    date: new Date(),
    encryptedContent: ciphertext,
    contentIv: iv
  }
});

Key Rotation

For added security, we support DEK rotation. When triggered, the process:

1. Generates a new DEK for the user
2. Decrypts all user content with the old DEK
3. Re-encrypts all content with the new DEK
4. Updates the DEK record in the platform database
5. Increments the key version

export async function rotateDEK(userId: string): Promise {
  const newDek = generateDEK();
  const oldDek = await getUserDEK(userId);

  // Re-encrypt all user content
  const entries = await vaultDb.dailyEntry.findMany({
    where: { userId }
  });

  for (const entry of entries) {
    const content = decrypt(
      entry.encryptedContent,
      entry.contentIv,
      oldDek
    );
    const { ciphertext, iv } = encrypt(content, newDek);

    await vaultDb.dailyEntry.update({
      where: { id: entry.id },
      data: {
        encryptedContent: ciphertext,
        contentIv: iv
      }
    });
  }

  // Update the DEK
  const { encryptedKey, iv } = encryptDEK(
    newDek,
    process.env.MASTER_ENCRYPTION_KEY
  );

  await platformDb.userDEK.update({
    where: { userId },
    data: {
      encryptedKey,
      keyIv: iv,
      keyVersion: { increment: 1 },
      rotatedAt: new Date()
    }
  });
}

Performance Considerations

Encryption adds overhead, but with proper implementation the impact is minimal:

What We Can Honestly Say

With this implementation, we can make strong privacy claims:

• Database breach: Attackers get ciphertext and encrypted DEKs – useless without MEK
• Admin access: We see encrypted blobs, not user content
• Subpoena: We can only provide encrypted data without the ability to decrypt
• Account deletion: DEK deletion = cryptographic data destruction
